Customize color L type power wire plug waterproof connector 2 pin
Customize color L type power wire plug waterproof connector 2 pin
P/N: AH-M20-2002Z01122
Material: Nylon
Color: Black
Certificate: CE/ROHS/SAA/UL
Shipping Port: Shenzhen China
Payment Terms: T/T bank, Paypal
Share to:
| PINs | Part Number | Wire Gague | Voltage | Current |
| 2 | AH-M20-2002Z01122 | ≤1.5mm² | 300V | 20A |
| 3 | AH-M20-2003Z01122 | ≤1.5mm² | 300V | 20A |
| 4 | AH-M20-1004Z01122 | ≤1.0mm² | 300V | 10A |
| Cable OD Range | 3.0mm-7.5mm |
| Operating Rating | -40℃ ~ +105℃ |
| Waterproof Level | IP67 |
Seal Ring:
| 5.0mm-6.5mm | φ6.5mm |
| 6.0mm-7.5mm | φ7.5mm |
| 7.0mm-8.5mm | φ8.5mm |
| 8.0mm-9.5mm | φ9.5mm |
| 9.0mm-10mm | φ10mm |
