Customized Panel Mount Male Plug Female Sockets IP67 IP68 Waterproof Wire Connector Solutions For Driver Power

This is waterproof connector processing with cable. The basic waterproof connector is assembly that can be solder or mold with the cable as requirement.

1.  Model: M20
2. Pin: 3pin
3. Connector type: front/rear panel mount
4. Plastic material: PA66
5. Metal material: gold plated brass
6. Rated Voltage: 300V
7. Rated Current: 15A
8. Wire Gauge: ≤1.5mm²
9. Cable OD: 5-10mm

Customizing waterproof wire connectors solution mean to customize male connector or female connector or even custom male and female together.  Male side can be inline type assembly connector, inline type molding connector, panel type connector in front panel or rear panel mount type, even cann be elbow (angle) connector; and the metal can be solder lugs or screw lugs. Female side also can be inline type assembly connector, inline type molding connector, panel type connector in front panel or rear panel mount type, even cann be elbow (angle) connector; and the metal can be solder lugs or screw lugs. But the most importance here is the male female connector can be the same type coming together. Because the male must match with female connector. So before order, please confirm the connector gender whether is compatible.

Assembly waterproof plug and socket Male: panel type front panel mount: AH-M20-1503FMF01112(solder type); AH-M20-1503FMF02122(screw type). rear panel mount: AH-M20-1503FMF01112(solder type); AH-M20-1503FMF02122(screw type). Female: inline type: AH-M20-1503MFZ01112(solder type); AH-M20-1503MFZ02122(screw type);	Customized waterproof plug and socket Male: panel type front panel mount: AH-M20-1503FMF01112(solder type); AH-M20-1503FMF02122(screw type). rear panel mount: AH-M20-1503FMF01112(solder type); AH-M20-1503FMF02122(screw type). Female: inline type: AH-M20-1503MFZ01112(solder type); AH-M20-1503MFZ02122(screw type); Female: molding type AH-M20-1503MFN01112 Female: elbow type AH-M20-1503MFL01112	Customized waterproof plug and socket Male: inline type  AH-M20-1503MMZ01112(solder type); AH-M20-1503MMZ01112(screw type) Female: customized as requirement assembly panel: front panel mount or rear panel mount; assembly panel plug: with inline housing; molding panel plug: mold with cable. panel plug soldered with electrical wire.

How to order?

Before order, please check the power and wire details, then compare to our datasheet, to choose the right connector for your application. If it is customized cable solution, it must send  a simple drawing with detail requirements to our safes to get further comfirmation. Our team will get back to you with CAD drawing for approval. In fact, we want to know the details includes:

1. connector type, such as panel type? with cable or without cable?
2. contact number, such as 2pin or 3pin?
3. working ampere?
4. wire gauge, cable OD, cable length?
5. request for stripped or tinned?

In a word, please send us detail requirement as possible as you can, then our engineer and sales will get back to you with drawing and price within 24 hours.
