Irrigation Automation And Monitoring Solutions Outdoor Male Female Power Signal Waterproof IP68 Cable Wire Connector 2+4pin
Irrigation Automation And Monitoring Solutions Outdoor Male Female Power Signal Waterproof IP68 Cable Wire Connector 2+4pin
- Contacts: 2+4pin
- Housing material: nylon
- Cable material: PVC
- Conductor: gold plated copper
- Voltage Rated: 110V
- Current Rated: 12A+4A
- Cable OD: 5-10mm
- Mechanical Life: 3000 cycle ratings
- Operating Temperature: -40℃~+105℃
- Waterproof Grade: IP67/IP68
- Certificate: CE/ROHS
- Shipping Port: Shenzhen China
- Payment Terms: T/T bank, Paypal
Share to:
Irrigation Automation And Monitoring Solutions Outdoor Male Female Power Signal Waterproof IP68 Cable Wire Connector 2+4pin
- Here is the 2+4pin waterproof connector. The bigger 2pin is used for power and smaller 4pin is used for signal.
- This connector is molded with cable directly.
- In general, the cable should be customized as you need.
- And cable length also customized as what you want.
Parameters
- Contacts: 2+4pin
- Housing material: nylon
- Cable material: PVC
- Conductor: gold plated copper
- Voltage Rated: 110V
- Current Rated: 12A+4A
- Cable OD: 5-10mm
- Mechanical Life: 3000 cycle ratings
- Operating Temperature: -40℃~+105℃
- Waterproof Grade: IP67/IP68
How to order?
- tell our salesperson with what you want, such as connector with cable or assembly type, it should be much appreciated if you can provide a simple drawing;
- we want to know the working ampere, wire gauge, and cable length you need.
- it would be better for us to understand what you want if you can tell us the usage of connectors.
- send all details to sales team and get quotation.
- start sample making and confirmation.
